Multi Analysis Flow Reactor System - Simulated Atmospheric Reactor

AF

AF

AF

FM

FM

FM

FM

MFC

MFC

Water bubbler

Acid  bubbler

Stirrer

Mixing chamber

sample

RH sensor

Refrigerated / heated circulator  (-50 oC to +200 oC)

Dry air flow

Dry air flow

Reactive gas(s)

Internal compartment of FTIR

Solar Simulator

ATR Crystal

IR beam

AF - Air filter

FM - Flow meter

MFC - Mass Flow Controller

MV - Meter valve

MV

Quadrapole RGA

Filament

gas molecules

quadrapole rods

Intensity

Absorbance

amu

wavenumber







Here, temperature is controlled by using a flow through jacketed ART crystal (PIKE Technologies) and a refrigerated/heated circulator (Julabo). Relative humidity is introduced by passing a controlled dry air flow through water bubbler and continually monitored via RH sensor attached to the reaction chamber. Simulated sun light (~ 1 sun)  is provided using a 150 W xenon solar simulator (Newport).
